Highsmorks Angular Directive

I was not very happy with how the highcharts-ng, which uses its own pretty much undocumented version of chartConfig for some bizarre reason.

The directive is called Highsmorks, only to create a fun unique name.

References

I highly recommend you go through the examples and API to learn how to use chartConfig.

HighStock API - http://api.highcharts.com/highstock HighStock Demos - http://www.highcharts.com/stock/demo

HighChart API - http://api.highcharts.com/highcharts HighChart Demos - http://www.highcharts.com/demo

HTML

Setting up a chart is easy.

<highsmorks id="chart1" chart-config="{{chartConfig}}" type="StockChart"></highsmorks>

Note "chart-config" this translates to chartConfig on the angular side.

JavaScript

To setup the chart, you will need to create a chartConfig. The chartConfig I'm using is exactly the same as defined in the reference.

Here is a very simple one for example:

$scope.chartConfig = {
    title: {
        text: 'Chart Title'
    },
    subtitle: {
        text: 'Chart Subtitle'
    },
    xAxis: {
        gapGridLineWidth: 0
    },
    scrollbar: {
        enabled: false
    },
    navigator: {
        enabled: false
    },
    rangeSelector: {
        enabled: false
    },
    series : [{
        name : 'Series Name',
        data: [[1420088400000,0.89],[1388552400000,47.56],[1357016400000,39.29]],
        tooltip: {
            valueDecimals: 2
        }
    }]
};

$broadcast Methods

There is two ways to pass in data to the chartConfig or you can use a $broadcast method if you are loading the data via AJAX.

addSeries

This adds a series to a chart, the object is as defined in the HighStocks API.

$scope.$broadcast('highsmorks',{
    id: 'chart1',
    method: 'addSeries',
    obj: {
        data: [[1420088400000,0.89],[1388552400000,47.56],[1357016400000,39.29],[1325394000000,25.16],[1293858000000,7.73]],
        name: 'ytds',
        type: 'area',
        gapSize: 5,
        tooltip: {
            valueDecimals: 2,
            valueSuffix: '%'
        }
    }
});

setTitle

Sets the title and/or subtitle dynamically.

$scope.$broadcast('highsmorks',{
    id: 'chart1',
    method: 'setTitle',
    obj: {
        title: 'New Title',
        subtitle: 'New Subtitle'
    }
});

redraw

Redraws the chart.

$scope.$broadcast('highsmorks',{
    id: 'chart1',
    method: 'redraw'
});

addPoint

Adds another point to a specific series.

$scope.$broadcast('highsmorks',{
    id: 'chart1',
    method: 'addPoint',
    seriesName: 'ytds',
    obj: {
        x: 1520088400000,
        y: -25.0
    }
});

Themes

If you want all of your charts in your app to follow the same theme, you may use a theme file along with the setOptions() method.

Example:

// Global Theme for Highcharts
Highcharts.theme = {
    colors: ['#50B432', '#ED561B', '#DDDF00', '#24CBE5', '#64E572', '#FF9655', '#FFF263', '#6AF9C4'],
    credits: { enabled: false }
};
// Apply the theme with setOptions().
Highcharts.setOptions(Highcharts.theme);

Comprehensive instructions are available from highcharts directly.

http://www.highcharts.com/docs/chart-design-and-style/themes

Examples

Doughnut chart for Market Capitalization

$scope.marketCapConfig = {
    chart: {
        plotBackgroundColor: null,
        plotBorderWidth: 0,
        plotShadow: false
    },
    title: {
        text: 'Market<br/>Capitalization',
        align: 'center',
        verticalAlign: 'middle',
        y: -15
    },
    tooltip: {
        pointFormat: '{series.name}: <b>{point.percentage:.1f}%</b>'
    },
    plotOptions: {
        pie: {
            dataLabels: {
                enabled: true,
                distance: -50,
                style: {
                    fontWeight: 'bold',
                    color: 'white',
                    textShadow: '0px 1px 2px black'
                }
            },
            startAngle: 0,
            endAngle: 360,
            center: ['50%', '50%']
        }
    },
    series: [{
        type: 'pie',
        name: 'Account Percent',
        innerSize: '50%',
        data: [
            ['Small Cap',   10.38],
            ['Other',       56.33],
            ['Large Cap',   24.03],
            ['Other',        9.26]
        ]
    }]
};

Simple Line Chart

Data gets added in later by using the broadcast method addSeries above.

$scope.chartCfg = {
    title: {
        text: ''
    },
    subtitle: {
        text: ''
    },
    xAxis: {
        gapGridLineWidth: 0
    },
    scrollbar: {
        enabled: false
    },
    navigator: {
        enabled: false
    },
    rangeSelector: {
        enabled: false
    }
};

// Later after ytds data is generated from an AJAX call.
$scope.$broadcast('highsmorks',{
    id: account.number,
    method: 'addSeries',
    obj: {
        data: ytds,
        name: 'ytds',
        type: 'area',
        gapSize: 5,
        tooltip: {
            valueDecimals: 2,
            valueSuffix: '%'
        }
    }
});
